Dimensions :2220*800*670MM
Channel size: 2000*700*600MM
Net weight: 40KG
Gross weight: 50KG
Main technical parameters
Probe location: 6 independent probe locations
Overall sensitivity: 0-199 grade
Working frequency band: F1-F12
Power consumption: < 30W
Passing speed: 0.4m/s-1.2m/s
Alarm mode: buzzer alarm, sound and light synchronization
Alarm duration: adjustable 1-3S
Operating voltage: 220VAC 50/60HZ
Ambient temperature: -10°-45°≤95%RH
Bill of materials
Item name quantity
Security door panel 1 set
Security door head 1 piece
Power Cable 1pcs
Three mainboard cables
Set screws 8 pieces
1 copy of warranty card, specification and qualification certificate
Matters needing attention
1. This security door can only be used indoors. If outdoor installation is required, please purchase waterproof security door or build awning.
2. Do not install the detection door in a high temperature or humid environment.
3. Non-professional personnel are not allowed to dismantle or repair the security door without authorization
4. The detection door self-test after starting 1-2 minutes to achieve the best test effect
5. When multiple security gates are used side by side, the spacing between each gate should be greater than or equal to 50CM, and the debugging should be conducted to different frequencies.
