Hydraulic station
* Institutional form: vertical
* Motor: 3HP * 4P, three-phase 380VAC (industrial)
* Power: 3.7KW.
* Cooling method: natural cooling structure
* Working temperature: -35 ° ~ 75 °
* Solenoid valve combination: electromagnetic directional valve, electromagnetic relief valve, pressure reducing valve, speed regulating valve
* Fuel tank capacity: about 60 liters
* Hydraulic pipe: PT international standard interface, 1/2 double-layer steel wire high-pressure pipe
* Emergency: Support standby manual ascending and descending.
* Double-action double-oil manual pump: 2.3ml / time (industrial grade)
Control System
Control system: Xinjie PLC American original chip
Control box: dusting process for pure outdoor use with LCD display
Self-test procedure: standard
Trial period setting: standard
Dark daybreak setting: standard
Security linkage: standard
Fire linkage: standard configuration
Air leakage switch: Chint
Contactor: Chint
Switching Power Supply: Taiwan Mingwei 220VAC (Industrial)
Lift column remote control: 100 meters (standard)
LED remote control: 2.4G 30 meters (standard)
Remote control switch: optional
